Qorvo TQL9062

Qorvo’s TQL9062 is a cascadable, high-linearity gain block amplifier in a compact 2 × 2 mm surface-mount package. At 3.5 GHz, the amplifier typically delivers 16 dB gain, +40.3 dBm OIP3, and a 1.5 dB noise figure (NF). The LNA can be biased from a single positive supply voltage ranging from 3.3 V to 5 V.

With its excellent noise figure and high linearity, the TQL9062 is ideal for receiver and transmitter chains in high-performance systems. The gain block utilizes a high-performance E-pHEMT process and features internal matching, requiring only four external components for operation from a single positive supply: an external RF choke and blocking/bypass capacitors.

This low-noise amplifier (LNA) incorporates an internal active bias circuit to maintain high performance over temperature and integrates a shutdown function for time-division duplexing (TDD) applications. The TQL9062 covers the 500–6000 MHz band, making it suitable for wireless infrastructure and other applications demanding high linearity and/or low noise.

Key Features

Frequency range: 0.5–6.0 GHz

Gain: 16 dB at 3.5 GHz

OIP3: 40.3 dBm at 3.5 GHz

ESD rating: Class 1C (HBM)

High input power robustness: 33 dBm CW

Shutdown control: 1.8 V TTL logic-compatible

Unconditionally stable

Integrated on-chip matching: 50 Ω input/output

Applications

Defense communications

FDD/TDD systems

Mobile infrastructure

Repeaters/DAS (Distributed Antenna Systems)
